Patented product - flip-top linear array sound reinforcement system

Inline array composed of two 75mm12-inch full-tone units and four 44mm tweeters, the base is a single 18-inch ultra-low frequency unit, and all units (7 units) of the system are made of neodymium iron boron material.

1100W+1100W+550W are installed at the middle connection position, DSP-controlled active power mode.

Press down, close it to push and carry it, flip it up and put it into use immediately, one minute installation.

Rated power: HMF: 900W, LF: 650W

Built-in module power: 550W+1100W+1100W

Impedance: HMF: 4 ohms, LF: 8 ohms

Diffusion angle: 100×30

Sensitivity: HMF: 103dB, LF: 104dB

Maximum sound pressure level: HMF: 132dB, LF: 132dB

Frequency response: HMF: 65Hz-19.5KHz LF: 34Hz-200Hz

Box material: HMF: 15mm plywood, LF: 18mm composite fireproof board

Unit structure: LF: 100ND, MF: 75ND@2, HF: 44ND@4

Box size: 580×910×1160mm

Packaging volume: 0.56m3

Net weight: 122.5kg

Gross weight: 125kg

Suspension: None
