Product Description:

The PS-8 multi-function speaker is a two-way speaker consisting of a 34-core tweeter with a constant directivity, asymmetric tweeter diffusion horn and an 8-inch woofer with a 50-core voice coil. It has high sensitivity, delicate timbre, clear sound and strong penetration, but the low-frequency lower limit is high. The speaker can be turned in four directions according to the needs of use to form a multi-box array or wedge-shaped monitoring in a horizontal or vertical position. Each speaker in the PS series is equipped with a variety of hoisting components for hoisting, fixed installation, and support installation.

Suitable places: close listening, places requiring high sound pressure and sound quality. Such as small cultural performances, nightclubs, bars, multi-function halls, conference rooms, etc.

Product parameters:

Rated power (W): 200

Impedance (Ω): 8

Diffusion angle: 100×50

Sensitivity (dB): 101

Maximum sound pressure level (dB): 122

Frequency response (Hz): 80-19K

Box material: 15mm plywood

Box size (W×D×H): 261×219×421

Unit structure (mm): LF:50Fe HF:38Fe

Packing volume (m3): 0.1 (2 pieces)

Net weight (kg): 10.5

Gross weight (kg): 27 (2 pieces)

Hanging: Yes

Frequency response diagram:
