Product Description:

The PS-10 multi-function speaker is a two-way speaker consisting of a 44-core tweeter with a constant directivity, asymmetric tweeter diffusion horn and a 10-inch woofer with a 65-core voice coil. It has high sensitivity, delicate timbre, clear sound and strong penetration, but the low-frequency lower limit frequency is high. The speaker can be turned in four directions according to the needs of use to form a multi-box array or wedge-shaped monitoring in a horizontal or vertical position. Each speaker in the PS series is equipped with a variety of hoisting components for hoisting or fixed installation or support installation.

Suitable places: close listening, places requiring high sound pressure and sound quality. Such as small cultural performances, nightclubs, bars, multi-function halls, conference rooms, etc.

Product parameters:

Rated power (W): 250

Impedance (Ω): 8

Diffusion angle: 100×50

Sensitivity (dB): 103

Maximum sound pressure level (dB): 127

Frequency response (Hz): 70-18K

Box material: 15mm plywood

Box size (W×D×H): 326×277×515

Unit structure (mm): LF:65Fe HF:44Fe

Packing volume (m3): 0.07

Net weight (kg): 14.5

Gross weight (kg): 18

Suspension: Yes

Frequency response diagram:
