Product Description:

R2 is an all-weather three-way speaker. The design uses a multi-layer glass fiber composite structure. The woofer is installed in a double-layer structure formed by the cabinet, which provides a completely rainproof and sealed cavity for dual LF drivers. The mid-range and high-frequency speakers are axially mounted on the woofer mouth. Contains a high-quality passive crossover network with dynamic driver protection.

Advantages: All-weather, long-range, high-power horn speaker system, waterproof, UV-proof, accurate projection.

Construction: 1. Inner and outer double-layer resin shell. 2. Stainless steel hardware fasteners. 3. Dual 12-inch carbon woven basin woofers. 4. 2 φ100 midrange, 1 φ44 tweeter. 5. 3-layer composite stainless steel mesh.

Suitable places: gymnasiums, stadiums, theme parks, playgrounds, track and field stadiums, open squares, competitive performance venues, aviation performance venues, racecourses, swimming venues, ferry electric bands, portable sound reinforcement systems.

Product parameters:

Rated power (W): 550

Impedance (Ω): 4

Diffusion angle: 60×40

Sensitivity (dB): 110

Maximum sound pressure level (dB): 136

Frequency response (Hz): 120-18K

Box material: composite polyester

Unit structure: LF:100Fe@2 MF:66Fe@2 HF:51Fe1

Box size (W×D×H): 630×738×630

Packing volume (m3): 0.47

Net weight (kg): 52

Gross weight (kg): 55 (PEM)

Suspension: Yes

Frequency response diagram:
