Product Description:

The i-6000 linear array speaker is a two-way speaker consisting of a 15-inch 100-core woofer and two 51-core tweeters. It uses built-in passive frequency division, and the cabinet is made of imported

birch wood. Its compact cabinet structure and painted exterior are more suitable for performances.

System Features: 1. This system is a linear array that can be stacked and placed on the ground, eliminating the complex hanging system of general linear array speakers, which greatly facilitates

 installation and use. 2. Perfect waterproof baffle design to prevent the interface from being disturbed by rain.

Use: 4 i-6000 speakers and 2 i-6000SUB speakers per channel, full-range use of 2 W10.2 amplifier bass with 1 W14.2 amplifier, and 1 DSZ6 processor can meet the performance of 4,000 people, with an

effective listening distance of 50 meters.

Product parameters:

Rated power (W): 550

Impedance (Ω): 8

Diffusion angle: 110×8

Sensitivity (dB): 99

Maximum sound pressure level (dB): 130

Frequency response (Hz): 60-18.5K

Box material: 18mm birch plywood

Unit structure: LF:100Fe HF:51Fe@2

Box size (W×D×H): 643×554×473

Packing size (W×D×H): 680×590×510

Packing volume (m3): 0.21

Net weight (kg): 52

Gross weight (kg): 55

Suspension: Yes

Frequency response diagram:
