Product Description:

The Q1 speaker adopts a passive two-way design, equipped with two 10'' 75-core low-frequency units and one 3-inch 75-core high-frequency compression driver unit, all made of aluminum iron boron magnetic materials, and the tweeter lens adopts a mature drum waveguide design. The 75° horizontal constant directivity characteristic can control the lower limit to 400Hz, and the 15° vertical high-frequency diffusion angle; the curve characteristic is smooth and the phase consistency is good, so that the Q1 can be used in vertical arrays and generate curved coherent wavefronts in front of the array. The mechanical structure of the speaker combined with the acoustic design allows the vertical coupling angle between each speaker to be adjusted between 0 degrees and 14 degrees. Users can combine 2 (15°-30°) diffusion angles) to 20 speakers according to the different conditions and requirements of the venue.

The Q1 cabinet is made of solid high-quality birch plywood, and the cabinet surface is coated with waterproof, wear-resistant and anti-collision paint. The front panel of the speaker is protected by a solid metal grid and covered with a replaceable acoustically transparent foam material. The side panel incorporates a pair of handles, and the rear panel is embedded with two EP5 or NL4 parallel interfaces. It is suitable for outdoor performances, stadium lighting, theaters and other high-demand professional occasions.

Product parameters:

Rated power (W): MF:800/HF:200

Impedance (Ω): MF:8/HF:8

Diffusion angle: 75×15

Sensitivity (dB): MF:102/HF:105

Maximum sound pressure level (dB): MF:131/HF:128

Frequency response (Hz): 60-17K

Box material: 18mm birch plywood

Box size (W×D×H): 580×307.7×392

Unit structure: LF:65ND/HF:75ND@2

Packing volume (m3): 0.12

Net weight (kg): 22

Gross weight (kg): 29

Suspension: Yes

Frequency response diagram:
