Product Description:

AR-628 is a 1200W high-power two-way professional road show speaker consisting of two 15-inch 100mm voice coils and a 75mm voice coil tweeter driver. It has the remarkable characteristics of large dynamics, high sound pressure, and long range. It uses an aviation cabinet shell with a simple system, convenient transportation and use, and is suitable for small and medium-sized performance sound reinforcement with strong mobility.

National patent product: Use oblique insertion concealed cast aluminum terminal box to increase the life of the equipment.

National patent product: Outdoor aviation cabinet audio.

Use 1.22mm Japanese fireproof board directly compounded on the shell of the speaker, and install aluminum alloy parts on all corners to prevent damage to the product due to external force collision. At the same time, spring hinges and universal wheels provide great convenience for transportation.

Product parameters:

Rated power (W): 1000

Impedance (Ω): 4

Sensitivity (dB): 102

Maximum sound pressure level (dB): 132

Frequency response (Hz): 45-18.5K

Box material: 18mm plywood composite fireproof board

Unit structure: LF100Fe@2 HF:75Fe

Box size (W×D×H): 497x662.5x1236

Packing volume (m3): 0.4

Net weight (kg): 94

Gross weight (kg): 94

Suspension: No
