AR2183 Boton Roadshow King - Ultimate Edition

It is specially designed for mobile performances. Wide bandwidth and high sound pressure kill the roadshow world in seconds. 4 ohms 1800 watts, maximum sound pressure level 143 decibels are hard indicators of high sound pressure.

AR2183 is a three-way system composed of 2 18-inch 100mm voice coil wide-band mid-bass units, a 100mm voice coil mid-high unit and a 51mm voice coil tweeter. The two 18-inch mid-bass units have been precisely physically phased to make the low frequency clean, strong and full. The double tweeters are designed as an integrated horn and installed independently to simplify production and maintenance. The 6 reinforcing ribs inside the box suppress resonance.

AR2183 adopts an aviation cabinet shell, and imported Japanese fireproof board is waterproof and anti-collision. 18mm birch plywood, 1.5mm aluminum alloy profile, 4-inch universal wheel, sunken wheel well, cast aluminum junction box. Make transportation and installation easy.

Suitable for medium and large performances, theaters, and stadiums.

Use oblique insertion and concealed cast aluminum terminals to increase the life of the equipment (patented project).

National patented product: outdoor aviation cabinet audio.

Use 1.22mm Japanese fireproof board directly on the shell of the speaker, and install aluminum alloy parts on all corners to prevent damage to the product due to external force collision. At the same time, the spring jaw universal wheel provides great convenience for transportation.

Product parameters:

Rated power (W): 1800

Impedance (Ω): 4

Diffusion angle: 90×60

Sensitivity (dB): 105

Maximum sound pressure level (dB): 143

Frequency response (Hz): 38-18.5K

Box material: 18mm plywood composite fireproof board

Box size (W×D×H): 516X680X1637

Unit structure: LF:100Fe@2 HF1:51Fe HF2:100Fe

Packaging volume (m3): 0.62

Net weight (kg): 125

Gross weight (kg): 125

Suspension: No
